Traction Nozzle

Pipe Range: 2" to 12" | Hose: 3/8" to 1 1/4" | Tier Three Fluid Mechanics

The KEG Traction Nozzle is a multi-purpose nozzle with a tight jet pattern that gives strong pulling thrust along with focused cleaning. Its rear jets alternate between 8 and 12 degrees, and KEG rates it as a Tier Three nozzle above 80% efficient.

Every size uses a 7 insert layout: 6 rear jets plus 1 forward penetrating jet that blasts through sand and mud or opens a path through heavy debris for other nozzles. Inserts can be titanium ceramic or steel. Stainless steel bodies fit 3/8" through 1 1/4" hose, and a lighter 1" aluminum version is offered for skid-mounted use.

Advantages

• Tier Three fluid mechanics, rated above 80% efficient by KEG
• Tight 8 and 12 degree alternating jets for strong pulling thrust
• Forward penetrating jet for sand, mud and heavy debris
• Runs as a penetrator, a cleaning nozzle, or both
• Replaceable threaded inserts in titanium ceramic or steel
• Suited to jetter trucks that run recycled water

Applications

• Sanitary and storm sewer cleaning
• Opening a path through debris for other nozzles
• Mud and sand removal
• Gentle cleaning of deteriorated pipe
• Small lines from 2" with 3/8" or 1/2" hose

Sizes and KEG Part Numbers

Choosing the Right Version

• The forward jet is a replaceable insert. KEG states its replaceable forward jet nozzles now include an additional blank steel insert; fitting the blank lets the Traction run as a cleaning nozzle with rear jets only.
• The 1" Aluminum version (107015) is rated for 4" to 10" pipe and must be run on a skid. KEG lists aluminum and stainless steel skids with holes in the accessories section of its catalog.
• Aluminum versions have a 1" hose connection; KEG notes they can be adapted to 1/2", 3/4" or 1 1/4" hose with a bushing.
• KEG lists a pulling eye option and other Traction accessories separately in its accessories section.
• Titanium ceramic and steel inserts share the same base KEG part number (KEG adds -C for titanium ceramic or -S for steel), so pick the insert material in the option selector.

How to Order Online

Select the size and insert material above. Before Add to Cart unlocks, enter your jetter's flow in gallons per minute (GPM), its operating pressure (PSI) and the length of your jet hose in feet. SECI uses these numbers to order the correct nozzle from KEG. KEG list pricing includes the nozzle, its inserts and the drill point where the nozzle has one.
