Palfinger

T22

description specs

The Palfinger T22 Hooklift is designed for heavy-duty applications with a 22,000 lb lift capacity. It features a telescopic jib that handles body lengths from 12 to 16 feet, offering versatility for a wide range of tasks. The T22 provides a maximum dump angle of 54° and includes a dual-pivot design for enhanced stability and efficiency. Constructed from high-strength A514 (T-1) steel, the T 22 is built for durability and long-term reliability in demanding environments.

S Model:

  • Lift / Dump Capacity: 22,000 lbs
  • CA Range: 115-125"
  • Optimum CA: 125"
  • Minimum GVWR: 26,000 lbs
  • Hooklift Length: 158"
  • Body Length Range: 10-14'
  • Optimum Body Lengths: 12-14'
  • Jib Height: 54"
  • Jib Action: Telescopic
  • Max Dump Angle: 52 degrees
  • Pivot: Dual
  • Number of Cylinders: 2/2
  • Operating Pressure: 3,300 PSI
  • Pump Type: Piston - Direct mount
  • Fitting Hoses: JIC/SAE

M Model:

  • Lift / Dump Capacity: 22,000 lbs
  • CA Range: 132-144"
  • Optimum CA: 144"
  • Minimum GVWR: 26,000 lbs
  • Hooklift Length: 176"
  • Body Length Range: 12-16'
  • Optimum Body Lengths: 14-16'
  • Jib Height: 54"
  • Jib Action: Telescopic
  • Max Dump Angle: 53 degrees
  • Pivot: Dual
  • Number of Cylinders: 2/2
  • Operating Pressure: 4,650 PSI
  • Pump Type: Piston - Direct mount
  • Fitting Hoses: JIC/SAE

L Model:

  • Lift / Dump Capacity: 22,000 lbs
  • CA Range: 144-160"
  • Optimum CA: 160"
  • Minimum GVWR: 26,000 lbs
  • Hooklift Length: 197"
  • Body Length Range: 14-18'
  • Optimum Body Lengths: 16-18'
  • Jib Height: 54"
  • Jib Action: Telescopic
  • Max Dump Angle: 51 degrees
  • Pivot: Dual
  • Number of Cylinders: 2/2
  • Operating Pressure: 4,650 PSI
  • Pump Type: Piston - Direct mount
  • Fitting Hoses: JIC/SAE
