description specs

Stellar designed this specialized hooklift from the ground up to meet the needs of municipalities and contractors who require a short, highly maneuverable, single-axle truck with a high payload capacity. Feedback from our distributors and operators indicated that a dump body would be the most common application for this truck.

Engineered for trucks with a cab-to-axle (CA) length of 84", the 96-10-24 model has proven its value nationwide in demanding, day-in, day-out operations. Beyond its primary use, the 96-10-24 has also demonstrated exceptional suitability for specialized tasks such as salt spreading, vacuum tanking, asphalt patching, and more.

96-10-24

  • Dump Angle (A): 54˚
  • Effective Length (B): 115"
  • Cab to Axle (C): 84" – 102"
  • Lift/Dump Capacity: 24,000 lbs
  • Recommended Body Lengths: 10' – 12.5'
  • Hook Height: 54"
  • Minimum Truck GVWR: 26,000 lbs
