DCL750TM25

description specs

The DLC750TM25 was value-engineered specifically for customers who need a full-sized (25 cyd), high-powered debris and leaf collection self-contained trailer at a budget-friendly price. We’ve kept it simple: A direct-drive vacuum system with all the capabilities and robustness and none of the extraneous components. Yet, we've retained what we at ODB know is important to ensure reliability, performance, and ease of use; a 74 hp John Deere Tier 4 engine, automotive-style PTO clutch, a 25-inch SHRED-MASTER™ fan impeller, ball bearings on boom swivel shaft, and of course, ODB build quality. Only ODB’s DCL750TM25 has these features in this product class.

Trailer

  • Bolted-on Pintle Eye
  • Axles: Heavy Duty Oil-Filled Leaf Spring (20,000LBS)
  • Electric brakes with breakaway actuator
  • Parking jack

Auxiliary Engine

  • 74 HP John Deere Tier 4
  • Cool-Flow™ protective pleated and boxed radiator air screen, with tool-free access
  • Fuel tank 40 Gallon polyethylene

Fan / Impeller

  • Direct drive
  • 25” SHRED-MASTER™ Fan Standard
  • Back plate protects bearings and shaft
  • Self-clearing
  • AR400 material
  • Fans are robotically welded, stress relieved and statically and dynamically balanced

Fan Housing

  • Robotically welded
  • Replaceable ¼” steel liners

Boom

  • Ball Bearing Boom Hose Swivel, top & bottom
  • Electric powered 12V boom
  • Hydraulic single axis boom (up/down)
  • 16” x 120” Urethane Vacuum Hose
  • Steel nozzle
