CCR

Lifting Capacity: 8,000 lbs (3,629 kg)
Dumping Capacity: 8,000 lbs (3,629 kg)
Transporting Capacity: 8,000 lbs (3,629 kg)
Container Sizes: 2 – 10 cubic yds
Type of Containers: Front and rear load
Rotation: Worm/Turntable Gear Bearings
Stacking Capability: 2 – 8 cubic yds
Operating Pressure: 4,500 psi (31 MPa)
GPM: 12 (45 LPM)
Hydraulic Tank: 10 gal (38 L)
Recommended CA: 84" to 114" (2,134 to 2,896 mm)
Controls: Inside and outside
Bushings and Zerks: All Pivot and Rotation Points
Container Bumpers: Molded Rubber
Hydraulic Pump: Bent Axis Piston Type
Valve Bank: 3-Spool Cable Controlled
Min. Chassis GVW: 26,000 lbs (11.8 MT)
C/L of Gravity: 12.25" Behind Rear Axle
C/L of Payload: 65.5" Behind Rear Axle
Shipping Weight: 3,000 lbs (1,361 kg)
